Fast | Flexible | Enduring
The ABUS NVR10011 network video recorder records video streams from up to 5 cameras at a total data rate of up to 60 Mbps. It offers storage for 2 internal hard drives and supports resolutions up to 3840 x 2160 pixels (4K-ready via HDMI output). Like all ABUS IP video recorders, the NVR10011 is flexible and scalable, allowing for integration into both new and existing projects.

Simple and clever
Setting up the IP cameras in the NVR is already easy thanks to the intuitive installation wizard. Furthermore, this NVR works seamlessly with, for example, ABUS IP cameras from the Advanced Line, which include intelligent alarm functions (Video Content Analysis, or VCA). In addition, the network recorder offers various alarm options: sending images via email, controlling a Central Monitoring Station (CMS) software with messages, or switching lights or an alarm siren.
Responding to different scenarios is very easy with the ABUS NVR10010. The network video recorder can be easily controlled via a local monitor, as well as remotely from anywhere in the world via app, ABUS CMS software, or a web browser.

Product benefits:

• Stream videos with a data throughput of up to 316 Mbps
• Integrate up to 5 IP cameras and up to 2 hard drives
• Resolutions up to 3840 x 2160px (4K-Ready) supported via HDMI output
• Perfect interplay between NVR and cameras with VCA functions
• Easy operation via local monitor, integrated web server, app or ABUS CMS software

• Dimensions (L x W x H): 315 x 380 x 50 mm
• Alarm inputs (NO/NC): 4
• Alerting: Acoustic warning signal, OSD signal, email, CMS, alarm output
• Views: 1 / 4 / 6 / 8 / 9
• Number of users: 31
• Number of HDDs: 2
• Number of channels: 5
• Audio: Line In: 1 x RCA (2.0 V peak-to-peak, 1000 Ω) – for network transmission only, Audio Out: 1 x RCA (600 Ω)
• Recording resolution @ frame rate per camera: 12 MPx, 8 MPx, 6 MPx, 5 MPx, 4 MPx, 3 MPx, 2 MPx, 1080p, 720p, VGA @ 25 fps
• HDMI output resolution: 4K (3840x2160)/60Hz, 4K (3840x2160)/30Hz, 1920x1080/60Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1024x768/60Hz
• VGA output resolution: 1920x1080p/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
• Recording modes: Manual, Schedule, Motion detection, Alarm input, VCA
• Recording time at 1080p @ 2 Mbit/s: 238 hours/TB
• Recording time at 6 MPx @ 8 Mbit/s: 60 hours/TB
• User levels: 3
• Operating mode: Triplex
• Operating temperature: -10 °C to +55 °C
• Data backup: 1 x USB 2.0, 1 x USB 3.0
• Decoder performance (live & playback): 4 x 6 MPx / 8 x 3MPx / 16 x 1080p / 32 x 720p
• Total frame rate (PAL): 125 fps
• Simultaneous network access: 128 camera connections
• HDMI Out: Yes
• Power consumption: 15 W
• Power consumption including HDD: 40 W
• Compliant with the Sarkozy Law (only valid for France): Yes
• Maximum humidity: 90%
• Mobile access: iDVR Plus / iDVR Plus HD (Apple iOS & Android)
• Monitor outputs: 1 x VGA, 1 x HDMI
• Multi-monitor function: Yes
• Net weight: 1 kg
• Total network throughput (input/output): 316 MBit/s (60 MBit/256 MBit)
• Network connection: 1 x RJ45 10/100/1000 Mbps
• Network functions: Live view, playback, data export, settings
• Network cameras: ABUS network cameras, 3rd-party (abus.com), RTSP
• ONVIF: Profile S
• PTZ control: Via network
• RAID: No
• RS-485 interface: No
• Relay output: 1 (load capacity: 12 V DC/1 A)
• Software: ABUS CMS Software, Integrated Web Server
• Power supply DC: 12 V
• Storage medium: 2 x SATA HDD (up to 6 TB per HDD)
• OSD languages: German, English, French, Dutch, Danish
• Control: USB mouse
• Search modes: Event, Date & Time, Smart Search, VCA
• Technology: IP
• Analog video channels: 0
• Total video channels: 5
• HD-SDI video channels: 0
• HD-TVI video channels: 0
• Video channels IP: 5
• Video compression: MPEG-4, H.264, H.265
• Certifications: CE, RoHS, Reach

• 1x Embedded NVR
• 1x USB wireless mouse
• 2x SATA cables
• 1x Recorder software (on CD)
• 1x Quick Start Guide
• 1x Mounting hardware
• 1x power supply
