Product information
Description
The ABUS NVR10051 network video recorder (NVR) records video streams from up to 64 IP cameras reliably and consistently. ABUS NVRs are characterized by their simple and flexible operation and can be integrated into any project as a scalable recording solution.
Product benefits:
Setup is very easy
Setting up the IP cameras in the NVR is very easy thanks to the intuitive installation wizard; the clear menu allows for quick programming. All current ABUS cameras are deeply integrated via protocol and therefore offer full functionality.
Free choice when operating the device
The local menu of the live view is clearly laid out and self-explanatory. Alternatively, the recorder can also be accessed via web browser, ABUS CMS software, or app.
ABUS Link Station
ABUS NVRs support the ABUS Link Station service. This allows for easy setup via the app, and internet access to the NVR is possible without complex port forwarding. Furthermore, the service offers a solution if only an IPv6 internet address is available at the location.
Product benefits:
- Recording and live viewing of up to 64 IP cameras @ 8 MPx (4K)
- Recording to up to 8 SATA hard drives
- Easy operation locally on the device, via web browser, ABUS CMS software or app
- Local monitor output supports up to 8 MPx (4K) resolution
- Manual or controlled recording according to schedule, motion detection, alarm input or VCA
- High-performance network data throughput of up to 576 Mbps (320 Mbps in / 256 Mbps out)
- Supports H.264 and H.265 (including Dynamic GOP)
- Redundant data recording using RAID (Level: 0, 1, 5, 10)
Details
- Dimensions (L x W x H): 450 x 440 x 95 mm
- Alarm inputs (NO/NC): 16
- Alerting: Acoustic warning signal, OSD signal, email, CMS, alarm output
- Views: 1 / 4 / 6 / 8 / 9 / 16 / 25 / 36
- Number of users: 31
- Audio: Line In: 1 x RCA (2.0 V peak-to-peak, 1000 Ω) – for network transmission only, Audio Out: 2 x RCA (600 Ω)
- Recording modes: Manual, Schedule, Motion detection, Alarm input, VCA
- Data backup: 2 x USB 2.0, 1 x USB 3.0
- Maximum humidity: 90%
- Power consumption: 30 W
- Monitor outputs: 2x VGA, 2x HDMI
- Net weight: 1.00 kg
- Relay output: 4 (load capacity: 12 V DC/1 A)
- Number of HDDs: 8
- Number of channels: 64
- Technology: IP
- Power supply: 100 – 240 V AC
- Storage medium: 8x SATA HDD (up to 10 TB per HDD)
- Language: OSD DE, EN, FR, NL, DK
- Control: USB mouse
- Search modes: Event, Date & Time, Smart Search, VCA
- Video compression: MPEG-4, H.264, H.265 (including Dynamic GOP)
- Network connection: 2 x RJ45 10/100/1000 Mbps
- User levels: 3
- Multi-monitor function: Yes
- Network functions: Live view, playback, data export, settings
- Simultaneous network access: 128 camera connections
- Mobile access: ABUS Link Station Lite / Pro (Apple iOS & Android)
- PTZ control: Via network, RS-485 interface, keyboard interface
- Network cameras: ABUS network cameras, 3rd-party (abus.com), RTSP
- Alarm inputs (NO/NC): 16
- Software: ABUS CMS Software, Integrated Web Server
- Hardware Watchdog: Yes
- RAID: RAID0, RAID1, RAID5, RAID10
- Resolution: Recording @ Frame rate per camera 12 MPx, 8 MPx, 6 MPx, 5 MPx, 4 MPx, 3 MPx, 2 MPx, 1080p, 720p, VGA @ 25 fps
- Operating temperature: -10 to +55 °C
- Total video channels: 32
- Analog video channels: 0
- HD-SDI video channels: 0
- Video channels IP: 64
- Total frame rate: 800 PAL
- Power consumption including HDD: 80 W
- RS-485 interface: Yes
- VGA output resolution: VGA1: 1920x1080p/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz; VGA2: 2K (2560x1440)/60Hz, 1920x1080p/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
- HDMI output resolution: HDMI1: 4K (3840x2160)/60Hz, 4K (3840x2160)/30Hz, 1920x1080/60Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1024x768/60Hz; HDMI2: 1920x1080/60Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1024x768/60Hz
- Recording time at 6 MPx @ 8 Mbit/s: 9
- Recording time at 1080p @ 2 Mbit/s: 37
- Decoding capabilities (local live view & playback): 4 x 6 MPx / 8 x 3 MPx / 16 x 1080p / 32 x 720p
Scope of delivery
- 1x Embedded NVR
- 1x USB wireless mouse
- 8x SATA cables
- 1x Quick Start Guide
- 1x Mounting hardware
