Product information
Description
Extensively expand alarm system
With this module
Expand your Secoris alarm system by 10 wired alarm detector groups to
to integrate additional detectors and components. Up to 50
BUS components (including extensions) and 200 detector groups per system
are possible. This allows you to secure even larger buildings completely. With
a wide range of wired detectors such as
Motion detectors/PIR sensors, glass break and smoke detectors, emergency call buttons
and door contacts.
Added value through building automation
The
The module optionally offers connection options for four relay outputs.
for controlling external devices (lights, roller shutters, etc.) and other
Features of smart building automation (required accessories:
4-way relay board (AZMO60010).
Simple wiring and installation
By
The bus wiring integrates the expansion module into the Secoris central unit.
integrated. Located in the building where needed – without effort for a
Individual cabling up to the central unit.
Product benefits:
- Expansion of the Secoris alarm center by up to 10
Wire detector groups
- Connection to the alarm control panel via BUS line, flexible from from everywhere in the building
- For decentralized wiring of the detectors without laying cables individual lines to the central office
- Compatible with a wide variety of wired detectors (e.g. (Building-integrated opening detectors, glass break detectors)
- Up to 50 BUS components (including extensions) per Secoris Headquarters
Details
- Number of wired detector groups: 10
- Number of radio detector groups: 0
- EN: Grade 3
- Dimensions (W x H x D): 144 x 230 x 44 mm
- Connections: RS485 bus, 10 wire alarm groups, 1 port for Plug-by communicator, 4 open collector outputs, speakers
- Housing material: ABS
- Integrated siren: No
- Maximum humidity: 93%
- Minimum operating temperature: -10 °C to +55 °C
- Mounting location: Surface-mounted
- Net weight: 0.42 kg
- Sabotage monitoring: Yes
- Switching outputs: 4 open collector outputs
- Power supply DC: 12 V
- Current consumption: 500 mA
- Environmental class: II
- Certifications: EN 50131 Grade 3, VSÖ GS-H
- Zone closure: CC/FSL
Scope of delivery
1x
Secoris BUS wire detector group extension
