Full power for the alarm system
ABUS Secoris is the alarm system for offices and commercial properties. The external BUS power supply BUMO 60100 is an expansion module for the Secoris alarm control panel.

Utilize maximum cable length
The external BUS power supply ensures that the maximum length of the BUS cable can be used in the Secoris system. It compensates for the voltage drop that occurs with increasing cable length in the BUS system.

LED status indicator
The system's status is easily readable on the colored LED display.

supplying power to components
In addition, the module supplies power to the Secoris wire components (e.g. Motion detectors) with power supply if required.

Reliable emergency power supply
The module also provides an emergency power supply to the Operation of the BUS components in the event of a severed main line or other malfunctions to ensure.

10 additional wire detector groups
In addition, the module offers connections for up to 10 Wired alarm groups. The alarm groups (CC, FSL) are freely programmable. and are monitored for sabotage (e.g., cutting cables).

Flexible voltage source
The bus power supply is powered by 230 V. Depending on The power requirements of the connected components will be met by a suitably sized battery. the module was used.

Certified quality
The BUS power supply is certified according to EN 50131-1 Grade 3.

Product benefits:

• ABUS Secoris – the alarm system for the reliable security of offices and commercial properties
• Additional power supply with emergency power supply (integrated battery)
• For larger installations and when utilizing maximum cable lengths, external power supplies offer the added benefit of increased performance.
• Can be used to ensure the safe operation of the alarm system in the event of malfunctions (e.g., severed main line).
• Provides up to 10 additional wire detector groups/lines
• EN 50131 Grade 3 certified

• Dimensions (W x H x D): 320 x 400 x 102 mm
• Connections: 230 V AC, 1 port for PlugBy communicator, RS485 Bus, speaker, 5-10 wire detector groups, LAN, 2 12V outputs, 4 open Collector outputs
• Outputs: 4 transistor switching outputs, 16 plug outputs
• Housing material: Metal
• Integrated siren: No
• Maximum humidity: 93%
• Mounting location: Surface-mounted
• Net weight: 4.9 kg
• Emergency power supply: optional (space for 12V battery with 17Ah)
• Sabotage monitoring: Yes
• Switching outputs: 4 open collector transistor outputs
• Power supply DC: 12 V
• Power supply AC: 230 V
• Environmental class: II
• Operating temperature: -10 to +55 °C
• EN Grade: 3
• Zone closure: CC/FSL
