The FUBE50001 wireless keypad with "rolling code" technology is an optional accessory for the Secvest FUAA50000 . It allows you to operate your ABUS alarm system using a PIN code or a proximity key fob. Up to eight wireless keypads can be integrated into the system and, installed at various building entrances, offer added convenience. In addition to arming and disarming individual zones, other switching tasks can be performed, such as opening and closing the garage door.

Product benefits:

• Power supply via battery or external power adapter (13.8 V)
• Activating/Deactivating the Secvest Alarm System
• Integrated proximity chip key reader
• Switching of outputs is possible
• LED indicator of current status
• Encrypted signal transmission (rolling code)

• Dimensions (HxHxD): 120x120x30 mm
• Battery type: 3 x AA (1.5V alkaline)
• Radio frequency: 868 MHz
• Radio power: 10 mW
• Housing material: ABS
• Maximum battery life: 1 year
• Operating temperature: -10 °C to +55 °C
• Maximum transmit/receive range (open field): 100 m
• Maximum transmit/receive range (indoors): 30 m
• Installation location: Interior
• Optional power supply: ABUS AZZU10011 (recommended for operation with chip key)
• Rolling Code: Yes
• Sabotage monitoring: Yes
• Security level: 2
• Voltage monitoring: Yes
• Power supply DC: 9-15 V (power adapter not included)

• Status indicator: 4 status LEDs for the sub-areas
• Current consumption: 100 mA

• 1x wireless control unit
• 3x AA alkaline batteries
• 1x Mounting material
• 1x Installation and operating instructions
