Product information

Description

For improved reception and range – the wAppLoxx Pro Repeater ACPA00007. For larger system expansions, the wAppLoxx Pro system offers greater range with the wAppLoxx Pro Repeater. Up to 32 cylinders can be integrated into a single repeater. Duplex antenna technology and the option to connect external antennas provide additional flexibility. A total of up to 6 repeaters can be used per wAppLoxx Pro Control unit, extending the wireless range between the CTRL and door components to up to 60 m.

Details

Areas of application: Indoor
Emergency power supply possible: Yes
Article short name: WLX-PRO-RP
Dimensions: 164 x 164 x 37 (L x W x H) mm
Battery type: Lead-acid gel (optional)
Housing material: Plastic
Programming: Programming/system administration via wAppLoxx Pro Control
DC power supply: 12V / 3A
Current consumption: 250 mA

Scope of delivery

1x WLX Pro Repeater
1x 12V/3A power supply
1x Quick Guide

Downloads

📄 Bedienungsanleitung
