Cost-saving PoE technology
For company premises, businesses, offices or homes: The ABUS 8 The MPx IP PoE Mini Tube camera is ideally suited for both indoor and outdoor use. The design is ideally suited for discreet wall-mounted surveillance. Power can be supplied, e.g., from the router or a recorder, via Network cables are used (Power over Ethernet, PoE) – especially useful at This saves on installation costs, especially in hard-to-reach locations.

Efficient commissioning & smart video surveillance
The ABUS TVIP68511 automatically distinguishes between Person and vehicle – it only stores and reports what users are interested in. This, along with the strong data compression, ensures a very efficient Storage usage (recorder, NAS or microSD card). Even the initial setup. It is kept slim: Via PC/browser or recorder/monitor as well as ABUS The IP installer allows quick access to the camera's user interface, so The first live image will be visible in a few minutes. Individual settings are also quick to create (e.g. schedules, private zones, etc.).

Powerful WDR function & IR LEDs for sharp images at all times Pictures
The IP camera also handles strongly fluctuating conditions. Lighting conditions, e.g. with a lot of backlighting in entrance areas or generally Outdoors (WDR 120 dB). It also features infrared LEDs for good visibility in... Darkness/Night.

Mobile app access
Users receive motion alerts via the ABUS Link Station app. a push notification. The Pro version of the app offers unlimited mobile data. Access. Free with the Lite version: up to 60 minutes/month data stream. (Live view/playback).

Product benefits:

• PoE surveillance camera for indoor and outdoor use, Ideally placed on the wall; small, powerful and versatile Security camera with professional features; saves to microSD, Recorder/NVR or NAS
• Power over Ethernet (PoE) with just one cable is extremely Reliably transmit video data to the router/switch/recorder and simultaneously Power the camera; power supply optionally via 12V DC plug-in power supply
• Streamlined setup in minutes via PC/browser or recorder/monitor and free ABUS IP installer (searches in the home network) or company network according to the camera's IP address)
• Fully automatic object recognition of persons and vehicles, Ignores interference such as branches or light, individual configuration via established user interface with schedules, private zones, etc.
• True WDR function (120 dB) for backlit situations, IR LEDs for night vision up to 30 meters (depending on location), wind & Weatherproof (protection class IP67, IK10), 4K resolution (Ultra HD, 8 megapixels) and a 107° viewing angle
• Compact dimensions/size (mini-tube design, length 17 cm) Ideal for discreet 24/7 video surveillance in offices or homes; through Motion detection requires less storage space and allows for faster location of the device. sought scene
• Recording via microSD memory card (accessory), Network video recorder (NVR) or NAS (Network Attached Storage); H.265 Plus video compression for longer recording times with high efficiency Storage space usage
• Easy mobile access to live stream and storage with Smartphone/tablet via ABUS Link Station app including push notification when Motion alarm (without router settings); info/images optional also via email/FTP

• Dimensions (L x W x H): 170 x 70 x 69 mm
• Alerting: Push-to-app, email, FTP, microSD recording
• Number of users: 32
• Resolution modes: Stream 1: 3840 x 2160 @ 20 fps, Stream 2: 640 x 480 @ 25 fps, Stream 3: 1920 x 1080 @ 10 fps
• Image sensor: 1/2.8" Progressive Scan CMOS
• Housing material: Metal
• Horizontal viewing angle: 107°
• IR range: up to 40 m
• Maximum humidity: 95%
• Power consumption: 6 W
• Minimum illuminance (color): 0.005 lx
• Minimum illumination (IR): 0 lx
• Net weight: 0.5 kg
• Resolution: 8 MP
• Protection class: IP 67
• IR LEDs: Yes
• Compatible with Secvest: Yes
• Compatible with wAppLoxx: Yes
• Technology: Network
• Power supply: 12 V DC (+/-25%)
• Storage medium: Optional microSD card (max. 256 GB)
• Language: OSD DE, UK, FR, NL, DK, IT
• Day/night switching: ICR/Color/B/W
• Video Compression: Stream 1: H.264, H.265, Dynamic GOP (+), Stream 2: H.264, H.265, MJPEG, Stream 3: H.264, H.265
• White balance: AWB, Manual
• Intended use: Outdoor/Indoor
• Focal length: 2.8 mm
• Lens mount: M12
• Encryption: HTTPS, TLS 1.1/1.2
• Supported browsers: Edge, Mozilla Firefox, Google Chrome
• PoE Standard: IEEE 802.3af
• Microphone: No
• Noise reduction: 3D DNR
• Dynamic range (WDR): 120 dB
• Private zones: 4
• Operating temperature: -25 to +60 °C
• Max. resolution @ frame rate: 3840 x 2160 @ 20 fps
• Image optimization: WDR, BLC, HLC, 3D DNR, Vertical Display (only in monitoring mode - no VCA)
• Video Content Analysis (VCA): Tripwire Detection, Intrusion Detection
• Vertical viewing angle: 55°

• 1x IP Mini Tube 8 MPx (2.8 mm)
• 1x power supply
• 1x Quick Start Guide
• 1x Safety instructions
