Product information
Description
SMALL CAMERA, BIG PERFORMANCE: FOR PROFESSIONAL SURVEILLANCE
The IP Mini Dome IPCB44511B delivers video streams in 4 MP resolution at up to 25 frames per second. Its vandal- and weather-resistant IP67 (IK08) housing allows for outdoor use, while integrated IR LEDs enable day and night operation. Mobile access to the camera is available via the ABUS Link Station app.
Automatic object recognition The security camera reliably distinguishes relevant movements (people, vehicles) from interferin...
Read more
Details
- Image sensor: 1/2.7" Progressive Scan CMOS
- Image elements (effective): 2688(H) x 1520(V)
- Minimum illuminance (color): 0.003 lx
- Minimum illumination (IR): 0 lx
- Dynamic range (WDR): 120 dB
- Electronic shutter: 1/3 - 1/100000 s
- Backlight compensation: WDR, BLC, HLC
- Image optimization: WDR, BLC, HLC, 3D DNR, Vertical Display
- Encryption: HTTPS, TLS 1.1/1.2
- White balance: AWB, Manual
- Day/night switching: ICR/Color/B/W
- Storage medium: Optional microSD card (max. 256 GB)
- Mounting type: Ceiling, wall
- Protection class: IK 8
- Dimensions (L x W x H): 109 x 109 x 58 mm
- Alerting: Email, NAS, FTP
- Connections: 1 x RJ45, 1 x DC
- Number of users: 32
- Resolution modes: Stream 1: 2688 x 1520 @ 25 fps, Stream 2: 640 x 480 @ 25 fps, Stream 3: 1920 x 1080 @ 10 fps
- Aperture at minimum illumination (color): F1.4
- Gross weight: 0.65 kg
- Digital zoom: Yes
- Features: Scene Change Detection, Region of Interest
- Housing material: Metal
- IR range: up to 20 m
- Camera type: Mini Dome
- Maximum humidity: 95%
- Power consumption: 8.5 W
- Net weight: 0.38 kg
- Network bandwidth for video: 32 kbit/s - 8 Mbit/s
- Resolution: 4 MP
- Protection class: IP 67
- IR LEDs: Yes
- Lens: Fixed
- Technology: IP
- Power supply: 12 V DC (+/-25%)
- Instructions in German, UK, FR, NL, DK
- Language: OSD DE, UK, FR, NL, DK, IT
- Current consumption: 650 mA
- Video compression: Stream 1: H.264, H.265, Dynamic GOP (+), Stream 2: H.264, H.265, MJPEG, Stream 3: H.264, H.265
- Video system: IP
- Frame rate: 1/16, 1/8, 1/4, 1/2, 1, 2, 4, 6, 8, 10, 12, 15, 16, 18, 20, 22, 25 fps
- Number: 2 IR LEDs
- Compatible with: NVR, ABUS Link Station App, ABUS Viewer
- Intended use: General monitoring
- Focal length: 2.8 mm
- Lens mount: M12
- Supported browsers: IE11, Mozilla Firefox, Google Chrome, MS Edge
- PoE Standard: IEEE 802.3af
- Network camera protocols: IPv4/v6, HTTP, HTTPS, FTP, SMTP, UPnP, DNS, DynDNS, NTP, RTSP, TCP, UDP, DHCP, ABUS Server, P2P, QoS, 802.1X, IGMP, Bonjour, PPPoE, SNMP
- Motion detection: max. 8 zones
- Microphone: No
- Number of streams: 3
- Noise reduction: 3D DNR
- Private zones: 4
- Operating temperature -25 to +60 °C
- Network connection: LAN RJ45 10M/100M self-adaptive
- Max. resolution @ frame rate: 2688 x 1520 @ 25 fps
- Video Content Analysis (VCA): Object detection (human & vehicle) with tripwire detection, intrusion detection, entry area, exit area
- ICR day/night function: Yes
- Other functions: Object classification person/vehicle
- Compatible with ABUS Link Station: Yes
- Compatible with Secoris: Yes
- Compatible with Secvest: Yes
- Compatible with wAppLoxx: Yes
- Compatible with wAppLoxx Pro: Yes
Lieferumfang
- 1x IP Mini Dome 4 MPx (2.8 mm)
- 1x Quick Start Guide
- 1x Safety instructions
- 1x adapter plate
Downloads
